High palladium content cp titanium sheet with annealed state for anti-corrosion industry
Item specifics
- Grade
- Gr5, Gr7, Gr9，Gr12, Gr23
- Thickness
- 0.5mm - 50 mm
- Width
- 10mm - 2000mm
- Length
- ≤3000mm
- Technology
- Hot-Rolled, Cold-Rolled, Hot forging , Machining
- Condition
- Cold rolled(Y), Hot rolled(R), Annealed (M)
- Surface
- Pickling surface, Polished surface, Black surface
- Specifications
- Aerospace, Medical, Industrial
Review
Description
As a titanium sheet supplier,our titanium sheet have been strictly inspected and the quality is guaranteed. our hot sell materials size are :1mm titanium sheet, 3mm titanium sheet,5mm titanium sheet.The following are detail informations about our titanium plates.
|
Grade |
Gr5, Gr7, Gr9, Gr12, Gr23 |
||
Standard | ASTMB265,ASTM F136,AMS4906,AMS4911 | ||
|
Thickness |
0.5mm - 50 mm |
||
|
Width |
10mm - 2000mm |
||
|
Length |
≤3000mm |
||
|
Technology |
Hot-Rolled, Cold-Rolled, Hot forging , Machining |
||
|
Condition |
Cold rolled(Y), Hot rolled(R), Annealed (M), Quenching(C)
|
||
|
Surface |
Pickling surface, Polished surface, Black surface |
||
|
Specifications |
Aerospace, Medical, Industrial
|
||
Chemical composition
Chemical composition, weight percent (%) | |||||||||||||||
Grade |
C ≤ |
O ≤ | N ≤ |
H ≤ |
Fe ≤ | Al | V |
Pd |
Ru | Ni | Mo | Other Elements Max. each | Other Elements Max. total | ||
Gr5 | 0.08 | 0.20 | 0.05 | 0.015 | 0.40 | 3.5～4.5 | — | — | — | — | 0.1 | 0.4 | |||
Gr7 | 0.08 | 0.25 | 0.03 | 0.015 | 0.30 | — | — | 0.12～0.25 | — | — | — | 0.1 | 0.4 | ||
Gr9 |
0.08 |
0.35 | 0.02 |
0.015 |
0.25 | 2.5～3.5 | 2.0～3.0 |
— |
— | — | — | 0.1 | 0.4 | ||
Gr12 |
0.08 |
0.25 | 0.03 |
0.015 |
0.30 | — | — |
— |
— | 0.6～0.9 | 0.2～0.4 | 0.1 | 0.4 | ||
Gr23 | 0.08 | 0.13 | 0.03 | 0.125 | 0.25 | 5.5-6.75 | 3.5～4.5 | — | — | — | — | 0.1 | 0.4 | ||
Physical properties
Grade | Physical properties | ||||||
|
Tensile strength Min |
Yield strength (0.2%, offset) |
Elongation in 50mm Min (%) |
|||||
ksi | MPa | Min | Max | ||||
ksi | MPa | ksi | MPa | ||||
Gr5 | 130 | 895 | 120 | 828 | — | — | 10 |
Gr7 | 50 | 345 | 40 | 275 | 65 | 450 | 20 |
|
Gr9 |
90 |
620 | 70 |
483 |
— | — | 15 |
|
Gr12 |
70 |
483 | 50 |
348 |
— | — | 18 |
Gr23 | 120 | 828 | 110 | 759 | — | — | 10 |
Tolerance (mm)
Thickness | Width tolerance | ||
400~1000 | 1000~2000 | ＞2000 | |
5.0～6.0 | ±0.35 | ±0.40 | ±0.60 |
6.0～8.0 | ±0.40 | ±0.60 | ±0.80 |
8.0～10.0 | ±0.50 | ±0.60 | ±0.80 |
|
10.0～15.0
|
±0.70
|
±0.80
|
±1.00
|
|
15.0～20.0
|
±0.70
|
±0.90
|
±1.20
|
|
20.0～30.0
|
±0.90
|
±1.00
|
±1.20
|
30.0～40.0 | ±1.10 | ±1.20 | ±1.50 |
|
40.0～50.0
|
±1.20
|
±1.50
|
±2.00
|
50.0～60.0 | ±1.60 | ±2.00 | ±2.50 |
Features :
High tensile strength;
High corrosion resistance;
Low density, good thermal stability;
Non-ferromagnetic;
Good bio-compatibility;
High temperature and low temperature resistance;
High resistance to strong acid and strong alkali and so on.
Application :
Chemical processing, medical instruments;
Aerospace, Industry, Navigation, Smelting;
Textile printing and dyeing;
Petrochemical industry;
Electroplating equipment;
Machining field, Automobile field;
Axis machining, the frame of the planes;
The equipment used in the sea water;
Nuclear industry;
Heat exchangers and condensers;
Construction industry etc.
Testing :
Chemical composition test,
Physical properties test,
Appearance defects inspection,
Ultrasonic flaw detection,
Eddy current testing.
